NovaChem Materials High-Purity Specialty Chemicals & Resins
● ISO 9001, ISO 14001 & Responsible Care Certified

Battery Grade LiFSI Salts, G5 NMP Solvents & Virgin PEEK

Synthesizing ultra-high purity specialty chemicals for lithium-ion battery gigafactories, semiconductor photolithography, and aerospace high-temperature polymer engineering.

99.99% LiFSI Assay
< 10 ppb Trace Metals (G5)
50,000 MT Annual Synthesis
UN Rated ISO Tank Containers
Battery Grade LiFSI Salts, G5 NMP Solvents & Virgin PEEK
Verified Production Facility • Direct Exporter ISO 9001 / CE Certified
Core Product Line

Engineered Products & Technical Specifications

Browse our export-certified product lines. Click "Technical Specs" for dimensional tolerance reports or "Inquire Now" for direct factory quotations.

Battery Grade Lithium Bis(fluorosulfonyl)imide 99.99% Solid White Crystal
NC-LIFSI-9999

Battery Grade Lithium Bis(fluorosulfonyl)imide 99.99%

  • Purity Assay ≥ 99.99% (HPLC Ion Chromatography)
  • Moisture Content ≤ 15 ppm (Karl Fischer Coulometric Titration)
  • Free Acid (HF) ≤ 10 ppm High Chemical Neutrality
Electronic Grade N-Methyl-2-pyrrolidone G5 Purity G5 Electronic Grade
NC-NMP-EL-G5

Electronic Grade N-Methyl-2-pyrrolidone G5 Purity

  • Assay ≥ 99.9% (Gas Chromatography)
  • Moisture ≤ 30 ppm High Anhydrous Purity
  • Metal Impurities Each Metal Ion < 10 ppb (ICP-MS Validated)
Ultra-Pure Virgin Polyetheretherketone (PEEK) Resin Natural Granules
NC-PEEK-450G

Ultra-Pure Virgin Polyetheretherketone (PEEK) Resin

  • Tensile Strength ≥ 100 MPa @ 23°C (ISO 527 Standards)
  • Melting Point 343°C High Heat Resistance
  • Continuous Service Temp 260°C Long-Term Working Temperature
Fluoroethylene Carbonate (FEC) Electrolyte Additive SEI Film Forming
NC-FEC-EL-99

Fluoroethylene Carbonate (FEC) Electrolyte Additive

  • Assay ≥ 99.95% (Gas Chromatography)
  • Water Content ≤ 20 ppm Karl Fischer
  • Free Acid ≤ 20 ppm as HF Equivalent
Manufacturing Infrastructure

Production Lines & Advanced Equipment

Our integrated manufacturing facility handles in-house tooling, high-precision machining, automated assembly, and testing under ISO 9001 certified protocols.

01

316L Stainless Distillation Columns

DCS-automated multi-stage vacuum fractional distillation towers equipped with structured packing for sub-ppm solvent purification.

Distillation Capacity: 15,000 MT/Year
02

Agilent ICP-MS Trace Metal Analyzers

Inductively coupled plasma mass spectrometers operating in Class 100 clean testing booths to detect 64 trace metal ions at parts-per-billion levels.

Detection Limit: < 0.01 ppb
03

Twin-Screw PEEK Polymerization Extruders

Coperion co-rotating twin-screw compounding lines with gravimetric feeders and underwater pelletizing for uniform resin granules.

Compounding Temperature: Up to 420°C
04

Nitrogen Blanketed Automated Drum Fillers

Sealed filling lines operating under ultra-pure nitrogen blankets to prevent atmospheric moisture pickup during packaging.

Nitrogen Purity: 99.999% Inert Seal
Quality Assurance

Standard Inspection Pipeline & Verifications

From raw material spectroscopy to final coordinate measuring machine (CMM) dimensional checks, every order is backed by comprehensive inspection reports.

01 / Raw Precursors

Spectroscopic Raw Chemical Verification

100% of incoming precursors analyzed by Fourier Transform Infrared (FTIR) spectroscopy and Karl Fischer titration.

02 / In-Process Synthesis

Real-Time Gas Chromatography & Titration

Continuous automated sampling monitoring reactant conversion rates and solvent reflux ratios.

03 / Clean Filtration

0.05 Micron PTFE Membrane Filtration

Solvents and liquid additives pass through sub-micron PTFE filters to guarantee zero particulate contamination.

04 / Pre-Shipment COA

Batch Specific Certificate of Analysis

Every drum and ISO tank issued with a comprehensive Certificate of Analysis detailing exact purity and trace metals.

👉 Swipe horizontally for full engineering tolerances & standards →
Component / Process Item Inspection Parameter Standard / Test Method Guaranteed Engineering Tolerance
Battery Grade LiFSI Salt Purity Assay & Metal Ions HPLC / ICP-MS Methodology ≥ 99.99% / Fe < 1.0 ppm
Electronic Grade NMP G5 Particle Count (≥ 0.5 µm) SEMI C31 Electronic Grade ≤ 25 particles/mL
PEEK Polymer Pellets Melt Viscosity & Ash Content ISO 1133 / ASTM D5630 Ash ≤ 0.05% / Clean Burn
Chemical Steel Drum UN Dangerous Goods Pressure Test UN 1A1 / Y1.4 Certified 250 kPa Hydraulic Seal OK
Global Export Readiness

Heavy-Duty Packaging & International Logistics

All export cargo is prepared according to strict international transit standards to guarantee zero moisture damage, corrosion, or mechanical impact during ocean or air transit.

UN Certified Packaging

UN Approved Steel Drums & IBCs

Heavy-duty UN certified 200L steel drums and 1,000L composite IBC containers with fluorinated inner linings.

ISO Tank Containers

Bulk 20ft T11 ISO Tankers

Insulated and steam-heatable T11 ISO tank containers for high-volume liquid deliveries to chemical ports globally.

Complete Dangerous Goods Declarations

IMO & Maritime Hazmat Paperwork

Complete Dangerous Goods Notes (DGN), GHS bilingual labels, and certified Material Safety Data Sheets.

Direct Factory Pricing

Request a Formal Quotation & Lead Time

Submit your specifications, target quantities, or CAD drawings. Our bilingual application engineering team will reply with an itemized formal quote within 2 business hours.

🔒 Bilateral Non-Disclosure Agreement (NDA) supported. All CAD drawings and company IP stored securely.

Product Specifications

Request Custom Drawing →
