Outdoor IP55 Rated
215kWh Liquid-Cooled C&I Energy Storage Cabinet
- Battery Capacity 215.04 kWh (3.2V 280Ah CATL / EVE Cells)
- Nominal Voltage 768 VDC Bus Voltage
- Thermal Management Active Liquid Cooling (Cell ΔT ≤ 2.5°C)
Turn-key battery energy storage containers, all-in-one solar+storage commercial cabinets, and intelligent energy management systems (EMS) for peak shaving, microgrids, and EV charging stations.
Browse our export-certified product lines. Click "Technical Specs" for dimensional tolerance reports or "Inquire Now" for direct factory quotations.
Outdoor IP55 Rated
Integrated PCS + STS
Standard ISO 20ft HC
Utility Interconnection
Our integrated manufacturing facility handles in-house tooling, high-precision machining, automated assembly, and testing under ISO 9001 certified protocols.
High-precision cell testing lines measuring OCV (open circuit voltage) and AC internal resistance with 0.1mV resolution before module laser welding.
Fiber laser welding cell executing copper-aluminum busbar fusion with zero thermal damage to cell terminal safety valves.
Helium mass spectrometer leak testing system validating cooling plate and hose joint integrity under 1.2 MPa test pressure.
High-power grid simulator and programmable load bank executing 100% round-trip efficiency, short circuit, and thermal run-in test cycles.
From raw material spectroscopy to final coordinate measuring machine (CMM) dimensional checks, every order is backed by comprehensive inspection reports.
100% of LiFePO4 cells undergo 4-point probe resistance measurement and 30-day self-discharge shelf audit.
High-speed machine vision verifies busbar weld bead width, spatter count, and laser penetration depth.
Dielectric strength test up to 3,500 VDC with insulation resistance verified > 100 MΩ.
Full cycle charging and discharging run-in with cloud telemetry verifying BMS cell balancing algorithms.
| Component / Process Item | Inspection Parameter | Standard / Test Method | Guaranteed Engineering Tolerance |
|---|---|---|---|
| LiFePO4 Battery Cell | AC Internal Resistance Matching | IEC 62620 / Tier 1 EVE/CATL | ΔR ≤ 0.05 mΩ per pack |
| Busbar Laser Weld Joint | Tensile Shear Pull Force | ISO 15614-11 Laser Standards | ≥ 1.8 kN Shear Force |
| Liquid Cooling Loop | Pressure Withstand & Leak Rate | UL 9540 / 1.0 MPa Glycol | Zero Pressure Drop / 30 min |
| BMS Voltage Sensor | Cell Voltage Measurement Error | GB/T 34131 / AEC-Q100 IC | ≤ ±1.5 mV (-20°C to +60°C) |
All export cargo is prepared according to strict international transit standards to guarantee zero moisture damage, corrosion, or mechanical impact during ocean or air transit.
All battery packs accompanied by official UN38.3 safety certificates, MSDS sheets, and Class 9 DG maritime export labeling.
20-foot and 40-foot containers equipped with heavy corner castings and structural ratings for international cargo ship stacking.
Full shipping arrangements to major international ports with hazardous goods shipping clearance.
Submit your specifications, target quantities, or CAD drawings. Our bilingual application engineering team will reply with an itemized formal quote within 2 business hours.
