Bidirectional Deflection
Steerable Electrophysiology Diagnostic Catheter
- French Size 4F / 5F / 6F Options
- Deflection Curve Bidirectional 180° Symmetric Curve
- Shaft Construction Stainless 304V Braid-Reinforced Pebax
Manufacturing bio-compatible disposable laparoscopic instruments, steerable electrophysiology catheters, micro-articulation robotic wrists, and high-purity medical extruded tubing.
Browse our export-certified product lines. Click "Technical Specs" for dimensional tolerance reports or "Inquire Now" for direct factory quotations.
Bidirectional Deflection
Clear Optical Tip
Tight Tolerances
7 Degrees of Freedom
Our integrated manufacturing facility handles in-house tooling, high-precision machining, automated assembly, and testing under ISO 9001 certified protocols.
Cleanroom continuous polymer extrusion line equipped with dual-plane Zumbach laser diameter gauges and lump detectors.
Steeger 16-carrier and 32-carrier automated fine-wire braiders for variable pitch stainless steel and nitinol catheter shafts.
Trumpf femtosecond pulsed laser workstation for ultra-fine stent strut cutting, hypotube spiraling, and marker band swaging.
Automated 15 m³ EO gas sterilization chamber with validated cycle parameters for medical device packaging release.
From raw material spectroscopy to final coordinate measuring machine (CMM) dimensional checks, every order is backed by comprehensive inspection reports.
100% of polymer batches verified for trace heavy metals, residual moisture, and initial endotoxin bioburden.
Real-time laser micrometers verify outer diameters every millisecond with automatic reel rejection.
Continuous particle monitoring ensuring air cleanliness conforms to ISO 14644-1 standards.
ASTM F1929 seal integrity testing and gas chromatography verification of ethylene oxide residuals.
| Component / Process Item | Inspection Parameter | Standard / Test Method | Guaranteed Engineering Tolerance |
|---|---|---|---|
| Multi-Lumen Tubing Wall | Wall Thickness & Concentricity | ISO 10555-1 | ±0.012 mm |
| Laparoscopic Trocar Seal | Pneumoperitoneum Gas Leakage | ISO 20695 / CO2 Test | < 5 mL/min @ 20 mmHg |
| Catheter Shaft Joint | Tensile Pull Force to Failure | ISO 10555-1 Clause 7 | ≥ 25 N (Exceeds Spec by 40%) |
| Sterilized Tyvek Pouch | Peel Strength & Seal Width | ASTM F88 / ASTM F1929 | 1.5 - 3.0 N/15mm Continuous |
All export cargo is prepared according to strict international transit standards to guarantee zero moisture damage, corrosion, or mechanical impact during ocean or air transit.
Medical-grade DuPont Tyvek pouches compatible with Ethylene Oxide and Gamma irradiation sterilization.
Products double-bagged inside cleanroom to allow sterile transfer into customer staging areas without contamination.
Rapid air delivery to medical OEM hubs in USA, Switzerland, Ireland, and Singapore.
Submit your specifications, target quantities, or CAD drawings. Our bilingual application engineering team will reply with an itemized formal quote within 2 business hours.
